Collection: GrindLazer Parts and Accessories

Which Graco GrindLazer do I have? · Versions, model numbers & manuals

Graco has built several versions of the GrindLazer. Find the model or part number on your unit's label and match it to a row below. Parts can differ between versions, so check the manual for your version before ordering.

Version	Model / part numbers	Graco manual
GrindLazer 270 / GrindLazer 390 / GrindLazer 480 / GrindLazer 630	571002, 571003, 571004, 571260	Parts list 3A0103 (rev. J) Operation manual 3A0101 (rev. F) Service manual 3A0102 (rev. E)
Graco DC1538 G DCS (High speed / Standard speed) / Graco DC1525 P DCS (High speed / Standard speed) / Graco DC1520 E DCS 480V (High speed / Standard speed) / Graco DC1520 E DCS 380V (High speed / Standard speed)	25P474, 25R100, 25P475, 25R101, 25P476, 25R102, 25P783, 25R103	Service manual 3A7600 (rev. E)
GrindLazer Standard DC87 G (200 cc / 6.5hp) (Standard Series - Forward Cut) / GrindLazer Standard DC89 G (270 cc / 9hp) (Standard Series - Forward Cut) / GrindLazer Pro DC89 G (270 cc / 9hp) (Pro Series - Forward Cut) / GrindLazer Pro DC1013 G (390 cc / 13hp) (Pro Series - Forward Cut)	25M842, 25M843, 25N667, 25M846, 25N668	Service manual 3A5578E Operation manual X006971 (rev. B)
GrindLazer Standard DC21 E / GrindLazer Standard RC7I E	25M841, 25N391, 25N609, 25M848, 25N392, 25N610	Operation manual 3A5575D
GrindLazer Pro RC813 G (390 cc / 13hp Electric Start) / GrindLazer Pro RC813 G (390 cc / 13hp Electric Start) (Series B) / GrindLazer Pro RC813 G DCS (390 cc / 13hp Electric Start)	25M847, 25N669	Service manual 3A5581 (rev. D)
GrindLazer HP DC89 G (270 cc / 9 hp) / GrindLazer HP DC1013 G (390 cc / 13 hp) / GrindLazer HP DC1021 G (627 cc / 21 hp Electric Start) / GrindLazer HP DC1013 G DCS (390 cc / 13 hp Electric Start)	25M992, 25M993, 25M994, 25N658, 25N659	Operation manual X007022 (rev. A) Service manual X006627 (rev. B)
GrindLazer DCS Control	18A790	Service manual 3A6922 (rev. A)
GrindLazer HP RC820 H (Hydraulic-Low Flow) / GrindLazer HP RC1640 H (Hydraulic-High Flow) / GrindLazer HP RC1625 G (Gas - 25HP Kohler)	25P471, 25P472, 25P473	Service manual 3A7398A
GrindLazer HP DC89 G (270 cc / 9 hp) / GrindLazer HP DC1013 G (390 cc / 13 hp) / GrindLazer HP DC1021 G (627 cc / 21 hp Electric Start) / GrindLazer HP DC1013 G DCS (390 cc / 13 hp Electric Start)	25M992, 18B306, 25M993, 18B307, 25M994, 25N658, 18B305, 25N659	Parts list 3A5929D
