Collection: Graco QuickShot Sprayer Parts & Accessories
Which Graco Ultra QuickShot do I have? · Versions, model numbers & manuals
Graco has built several versions of the Ultra QuickShot. Find the model or part number on your unit's label and match it to a row below. Parts can differ between versions, so check the manual for your version before ordering.
| Version | Model / part numbers | Graco manual |
|---|---|---|
| QuickShot | — | Service manual 3A9322F |
| Ultra QuickShot / Ultimate QuickShot | 20B473, 826308, 20B476, 20B477, 20B478, 20B479, 20B475 | Owner's manual 3A9301 (rev. K) |
| QuickShot II | — | Service manual X058396 (rev. B) |
| Ultra QuickShot II / Ultimate QuickShot II | 26E006, 26E007, 26E008, 26E009, 26E010, 26E011, 826319 | Operation manual X048114 (rev. C) |
Links open the PDF on graco.com. Need help identifying your version? Call (888) 714-1410.
Every replacement part for your Graco QuickShot Cordless Handheld Airless Sprayer, cross-referenced directly to Graco's official parts manual (3A9322EN-D). Pittsburgh Spray Equipment is a full-line Graco distributor — the parts on this page are genuine Graco OEM, not aftermarket.
📘 Graco QuickShot Repair Manual (PDF)
Exploded diagrams, torque specs, service procedures, and complete parts list. Download 3A9322EN-D.pdf →
What's covered
- Pump assembly + rebuild kits (18H072)
- Needle valve, solenoid, trigger switch (18H056, 18H057)
- Bare applicator kit + housing parts (18H059)
- Cup, lid, and gasket kits (18H078, 18H079)
- 60-mesh and 100-mesh filters (18H073)
- Prime knob and prime/spray valve
- RAC X FFLP fine-finish switch tips
- OEM DeWalt 20V battery kits (17P557)
- Fasteners, o-rings, seals, and warning labels
Why buy from Pittsburgh Spray Equipment
- Same-day shipping on in-stock parts ordered by 2 PM ET
- Factory-authorized Graco distributor — every part is OEM
- Free tech support by phone if you're not sure which part you need
- Repair kit bundles that follow the Graco service procedure
Related Graco parts collections
- Graco Ultra Max 695 Parts
- Graco 395 Airless Sprayer Parts
- Graco Magnum X5/X7 Parts
- All Airless Paint Sprayers
Not sure which part you need? Call our team at (888) 714-1410 or send the sprayer's model + serial number and we'll look it up against the Graco parts manual for you.
-
