Which Graco Merkur do I have? · Versions, model numbers & manuals
Graco has built several versions of the Merkur. Find the model or part number on your unit's label and match it to a row below. Parts can differ between versions, so check the manual for your version before ordering.
| Version | Manual date | Model / part numbers | Graco manual |
|---|---|---|---|
| Piston and Rod Packing Kit | 2011 | 24A655, 24J858, 24A656, 24J859, 24A657, 24J860 | Parts list 406845 (rev. D) |
| Merkur ES Spray Packages Instructions/ | — | 24F150, 24F151, 24F152, 24F153, 24F154, 24F155, 24F156, 24F157, 24F158, 24F159, 24N548, 24W281, 24W283, 24W285, … | Service manual 3A0732 (rev. U) |
| Merkur Non-Heated Airspray Packages Instructions- | — | G03Wxx, G03Cxx | Operation manual 3A7003C |
| Merkur High Pressure Sprayer Instructions- | — | 16U920, 16U918, 16V174, 16V175 | Service manual 332245 (rev. H) |
| Merkur Pump Assembly | — | W03EAS | Service manual 312794 (rev. M) |
| Flat Line Spray Systems Kits | — | 24F592, 24F595, 24F590, 24F591, 24F593, 24F594 | Service manual 3A1203B |
| Merkur Electrostatic Spray Packages | — | G30W86 | Service manual 312798 (rev. W) |
| Merkur Non-Heated Spray Packages | — | G10Cxx, G10Wxx, G15Wxx, G15Cxx, G15Txx, G18Wxx, G18Cxx, G23Wxx, G23Cxx, G24Wxx, G24Cxx, G28Wxx, G28Cxx, G30Wxx, … | Operation manual 312797 (rev. ZAF) |
| Merkur Heated Spray Packages | — | G30W82, G28C18, G28Wxx, G28Cxx, G30Wxx, G30Cxx, G36Cxx | Service manual 313255 (rev. V) |
| Merkur Bellows Pumps Piston Kits | 2010 | 24F488, 24F489, 24F490 | Parts list 406873 (rev. B) |
| Merkur Bellows Pump Bellows Chamber Kits | 2010 | 24E758, 24E759, 24E760 | Parts list 406854 (rev. C) |
| Other Graco manuals for these models | — | — |
Parts list 406848 (rev. C) Service manual 3A7004 (rev. C) Service manual 312799V Parts list 406851 (rev. B) Parts list 406870 (rev. B) Parts list 407054 (rev. B) Service manual 406846 (rev. C) Service manual 312795 (rev. K) Service manual 312792 (rev. L) Service manual 312793 (rev. M) |
Manual date = the revision date printed on Graco's document, not the production years. Links open the PDF on graco.com. Need help identifying your version? Call (888) 714-1410.
