Collection: Graco LineLazer V 130HS Parts

Which Graco LineLazer 130HS do I have? · Versions, model numbers & manuals

Graco has built several versions of the LineLazer 130HS. Find the model or part number on your unit's label and match it to a row below. Parts can differ between versions, so check the manual for your version before ordering.

Version	Model / part numbers	Graco manual
LineLazer IV 130HS Airless Line Striper	257780, 287025	Operation manual 313775 (rev. E)
LineLazer V 130HS	17H447, 17H448, 25P336, 25P337, 2012212	Parts list 3A3391 (rev. D) Operation manual 3A3392D

Links open the PDF on graco.com. Need help identifying your version? Call (888) 714-1410.

About Graco LineLazer V 130HS Parts · 224 in stock · Manual · Buying Guide · FAQ

Every replacement part for the Graco LineLazer V 130HS line striper ships direct from Pittsburgh Spray Equipment . Genuine OEM only. Same-day part identification: call (888) 714-1410, email sales@pittsburghsprayequip.com, or text a photo of your ID plate to (833) 670-5756.

Engine: Honda GX120

Owner's Manual

LineLazer V 130HS Owner + Parts Manual

Common Repair Categories · Why Buy from PSE · FAQ

Common Repair Categories

Pump service — packings, piston rods, seats, rebuild kits
Filters & strainers — inlet strainer, gun filters
Hoses & fittings — 50-ft airless hose, whip hose, quick-disconnects
Guns & tips — LineLazer guns, HD RAC tips, tip guards
Wheels & drive — front caster, rear wheels, wheel bearings, tie-rods
Engine & throttle — Honda GX120 parts, throttle cables, spark plugs
Seals & gaskets — pressure adjustment, o-rings, packing kits

Use the filter menu above the product grid to narrow by category.

Why Buy Genuine OEM from Pittsburgh Spray Equipment

Genuine OEM parts shipped from Graco
Same-day part ID help — text a photo of your machine's ID plate to (833) 670-5756
Financing available on machines over $1,000
Ships direct from stocked Pittsburgh warehouse

FAQ

What engine does the V 130HS use?
The Graco LineLazer V 130HS is powered by a Honda GX120 gas engine (smaller than the GX160 used in the 200HS/3900/5900 — matches the lower pressure output of the 130HS class).

Is the V 130HS a good fit for parking-lot striping?
Yes — the V 130HS is Graco's entry-level gas single-gun striper, sized for property maintenance, small parking lots, and short-run athletic field lines. If you need higher throughput or dual-gun operation, step up to the V 3900 or V 5900.

What tip sizes work with the V 130HS?
The V 130HS uses standard Graco LineLazer HD RAC tips. Most striping applications use .015-.019; smaller tips give narrower crisper lines but require slower walking speed.

Can I run the V 130HS on ethanol-blended gas?
Yes, up to E10 (10% ethanol). Higher ethanol blends can degrade fuel lines and carburetor seals over time. If the machine sits between seasons, add fuel stabilizer or run the tank dry before storage.
