Tiger Lifting SCB-0500 SS20 Corrosion Resistant 5tonne Chainblock

The SS20 is manufactured from the highest quality steel materials precisely machined in our own factory, offering a lightweight, compact and rugged construction, producing an exceptionally strong product resistant to impact damage.  The especially low headroom allows for easy installation in the most restricted environments. The unique design features listed below give it significant safety advantages over standard chain blocks and make the SS20 Chainblock the ideal tool for saltwater use with low maintenance and servicing costs

Key design features such as Tiger's patented brake pawls and deep pocket design hand wheel along with the full and comprehensive testing regime we have submitted our SS20 hoist to provide the evidence that allows us to state that these units can be safely used for “fleeting”, “drifting” and “cross-hauling” applications up to 60° from the vertical without deration

Capacity: 5tonne

Number of falls of loadchain: 3

Weight: 37.5kg (based on 3mtr lifting height)

Main features:-

• Suitable for use in multi-immersion applications
• DNV GL Verification tested according to NORSOK R-002
• Patented Quad Cam Pawl System – proven reliability
• Phosphor Bronze Bearings
• Tested and certified for “fleeting”, “drifting” and “cross-hauling” applications up to 60° from the vertical without deration
• Guaranteed 2% light load protection
• Fully Corrosion protected body and components to ensure reliable long-term use
• Over 1500 hours protection to ASTM B117 conditions
• Double cover protection for brake chamber
• Marine chain bags available on request
• Available with slipping clutch overload protection
