This tool is meant to aid in the removal of bell cups that are abnormally tight on the spindle shaft. Typically, bell cups are easily removed by hand with the aid of the standard bell cup wrench (A12061-00). To prevent bell cups from becoming difficult to remove, care should be taken to remove wet or old dried paint from shaft and bell cup taper and threads before bell cups are assembled to the atomizer.
Before using the bell cup removal tool, clean the exterior of the bell cup with clean solvent and dry it. This will improve the tool’s ability to grip the cups surface.
To install the tool, first engage the bell cup wrench (A12061-00) to the shaft hex behind the bell cup. Place the bell cup tool (A14208-00 (65mm)) over the front of the bell cup and tighten the knurled portion in a counter-clockwise direction until very tight (left hand thread). (See “Bell Cup Removal Tool” figure for proper engagement of the tool on bell cup.) While holding the bell cup wrench on the spindle shaft, grasp the pivoting handle on the bell cup tool and turn in a counter-clockwise direction until bell cup is loosened. If tool rotates or slip, tighten tool further and retry.
