Built for automotive shops and other low-production work, the DCM-161 automatically strips rust and carbon buildup off small hardware. The basket holds 2 gallons — up to 25 pounds of brake parts, engine components or other small pieces — and the machine runs itself on a 60-minute manual reset timer while you do something else.
The smallest way into automated blasting
At 17 cfm at 60 psi this is the rare blast machine that will run on a normal shop compressor instead of needing a dedicated one. That, plus 115V single-phase power and a benchtop-scale cabinet, is what makes it practical for a two-bay shop that could never justify a production cabinet.
What's included
- Door-mounted ZERO automatic gun with a #5 ceramic nozzle and a #4 orifice
- 100-cfm exhaust fan drawing dust into the bag filter
- Manual reset 60-minute timer
- 2-gallon tumble basket, 25 lb load limit
- Suction blast system suited to most fine-mesh media
Note this is a dust-bag machine, not a reclaimer machine — media is not cleaned and returned the way it is on the BNP-160 and larger cabinets. For occasional batches that is usually the right trade; for daily production it is not.
Common applications
- Remove residual sand from metal castings
- Beautify steel, stainless steel, aluminum, brass and other metals with a uniform matte finish
- Remove burrs, parting lines, flashings and other defects from castings and injection-molded parts
- Shot peen springs, journals, bearings, valve stems and tools to enhance strength and reliability
- Clean mold release and material buildup from molds
Specifications
| Cabinet dimensions | 12" W x 18" D x 24" H |
| Door size | 12" W x 12" H |
| Chamber capacity | 2 gallons |
| Chamber dimensions | 8" long x 9" diameter |
| Basket load limit | 25 lbs |
| Chamber door size | 5-1/2" x 6" |
| Tumble drive motor | 1/2 hp |
| Blast gun | 1 — #4 ZERO gun |
| Air consumption | 17 cfm @ 60 psi |
| Minimum air supply | 1/2 in. NPT |
| Reclaimer | none — dust bag collection |
| Dust collection | 150 cfm dust bag |
| Electrical | 115V / 1 ph / 60 Hz |
| Full load amperage | 14.8 |
| Shipping weight | 180 lbs |
Specifications, electrical requirements and air consumption vary with options, configuration and production requirements.
Sizing help
If you are running batches every day, or you want the media cleaned and reused, step up to the BNP-160 tumble basket cabinet — it adds a reclaimer and a reverse-pulse dust collector for the same 25 lb load. Call 888-714-1410 and we will tell you honestly which one fits your duty cycle.
