The EMAX ERI0070003-460 is a 7.5 HP fixed speed industrial rotary screw air compressor that delivers 24 CFM at up to 145 PSI from a 460V, 3-phase electric supply. It is a cabinet-only unit with no tank, built around an oil-injected rotary screw air end with an estimated 60,000-hour pump life. It suits industrial plants and operations that need continuous, steady airflow and already have, or plan to add, their own air receiver.
Rotary Screw Air End
Oil-injected design: The air end compresses air with an oil-injected male and female rotor and runs relatively quietly.
Duty cycle: EMAX rotary screw air ends are engineered for up to 100% duty cycle.
Continuous airflow: The screw design produces continuous, steady airflow for applications where consistent air delivery is a must.
Reliability and durability: Rotary screw air ends hold up in harsh conditions. Mining rigs, construction rigs, and firefighting equipment manufacturers choose them for that reason.
Estimated pump life: This model is rated for an estimated 60,000 hours of pump life.
Fixed Speed Operation and Output
Constant speed: The compressor runs at the same RPM throughout every run cycle and does not vary its speed.
Airflow: Delivers 24.01 CFM.
Pressure: Maximum pressure is 145 PSI from a single-stage pump.
Multi-Belt V-Belt Drive
Two-belt system: EMAX uses a multi-belt drive with B and C-width belts instead of a narrow, single A-width belt.
Better grip: The wider belts provide more surface area for grip.
Less bearing strain: Reduced belt tension lowers the load on the motor and compressor bearings.
Longer life: Lower noise and vibration help extend belt and system life, for a durable, low-maintenance drive.
Motor and Electrical
Motor: 7.5 HP TEFC motor running at 1,750 RPM.
Power: Requires a 460V (+/- 10%), 3-phase supply.
Amperage: Full load amps are 10.4 (including the 1.15 service factor), and locked rotor and peak starting amps are 66.2.
Breaker: A 15-amp breaker is recommended.
Certifications: Listed as UL/CSE certified.
Maintenance and Footprint
Oil capacity: Holds 1.33 gallons of oil.
Service kit: Uses service kit SKIT001AWB.
Uncrated size: 33" L x 24" W x 42" H, weighing 660 lbs.
Crated size: 48" L x 43" W x 49" H.
Need help sizing a rotary screw compressor, receiver tank, or electrical service for your shop? Call Pittsburgh Spray Equipment at 888-714-1410 and our team will help you choose the right setup.
Specifications — ERI0070003-460
| HP | 7.5 |
| Voltage +/- 10% | 460 |
| Phase | 3 |
| Drive Type | Electric |
| CFM | 24.01 |
| Silent Air | N |
| Smart Air | N |
| Compressor Type | ROTARY |
| Motor Type | TEFC |
| Belt Count | 2 |
| Pump Stage | 1 |
| Pump Riser | N |
| Belt Tensioner | N |
| Mag Starter | N |
| Radiator | N |
| Peak Starting Amps | 66.20 |
| Motor RPM | 1750.00 |
| FLA + 1.15 Service Factor | 10.40 |
| Locked Rotor Amps | 66.20 |
| Recommended Breaker | 15.00 |
| Max PSI | 145.00 |
| Uncrated Length | 33 |
| Uncrated Width | 24 |
| Uncrated Height | 42 |
| Crated Length | 48 |
| Crated Width | 43 |
| Crated Height | 49 |
| Oil Capacity | 1.33 |
| Oil U/M | Gallons |
| Estimated Pump Life (Hours) | 60000.00 |
| Certifications | UL/CSE |
| Service Kit | SKIT001AWB |
