General Pump T921 1700 PSI @ 5.0 GPM Gas Flange Triplex Plunger Replacement Pressure Washer Pump

General Pump T921 1700 PSI @ 5.0 GPM Gas Flange Triplex Plunger Replacement Pressure Washer Pump

Regular price
$1,042.00
Sale price
$1,042.00
Quantity must be 1 or more


Solid shaft with pump rails 24mm shaft 1/2” BSP-F inlet, 3/8” BSP-F outlet

FEATURES:

  • The preferred pump frame in the cleaning industry
  • Forged brass manifold with an exdlusive lifetime warranty
  • Large capacity, die cast, anodized aluminum oil bath crankcase
  • Over sized connecting rods for maximum life
  • Heavy duty tapered roller bearing
  • Solid ceramic plungers with continuously lubricating packings
  • Unitized stainless steel inlet and discharge valves
  • Available in left handed "L" version

Triplex Plunger Pump

  • Maximum volume: 5.0 GPM
  • Maximum Discharge Pressure: 1700 PSI
  • Maximum Inlet Pressure: 125 PSI
  • Maximum Pump Speed: 1050 RPM
  • Minimum Horsepower requirements: 5.8 bhp (8.8 hp for gas engines)
  • Bore: .866" (22mm)
  • Stroke: .630" (16mm)
  • Crankcase Capacity: 33.8 oz. nondetergent SAE 30W oil.
  • Maximum Fluid Temperature: 165 degrees F.
  • Inlet Port Thread: 1/2" FPT
  • Discharge Port Thread: 3/8" FPT
  • Shaft Diameter: .945" (24mm)
  • Dimensions: 11.4" x 9.2" x 6.9"
  • Weight: 30 lb.

Lubrication: Fill the crankcase to the dot on the oil gauge window per specifications with SAE 30W oil. Change the oil after a 40 hour break-in period, then every 3 months or 500 hour interfals thereafter.


;
