Riser
Our pump mounting plate riser is designed to raise the pump, allowing 360-degree airflow from the flywheel to cool the pump oil reservoir. Pump mount risers also allow air to flow under the pump for maximum cooling.
Continuous Run/Dual Control
Dual Control
Dual control allows users to run the unit with automatic start/stop control or the optional continuous run setting during high-duty cycle peak demand periods.
Optional Settings
The optional continuous run setting allows the pump to cool internally and saves the electric motor and magnetic switch from excessive frequent starting and stopping.
Pressure Lube
Pressure Lubrication is a more technically advanced and precise method to deliver oil to critical parts of the pump, resulting in longer pump life. The oil is pumped through an oil filter and into the pump, where it is then recycled and reused. Since the oil pump delivers oil more efficiently, the viscosity of the oil is less critical than with a splash system. In the air compressor industry, upgrading to pressure lubrication systems is typically more costly.
Silent Air
Noise Reduction
Our Patented Silent Air system dissipates compressor intake noise through a series of noise cancellation plates, reducing DBA ratings by up to 50%. Silent air compressors operate at a normal conversation level compared to traditional compressors that operate at the level of a police siren.
Air Filtration
This low-profile system not only makes the compressor quieter but also adds four levels of air filtration.
Silent Air Technology
- Significantly lowers the risk of hearing damage
- Decreases employee turnover
- Enhances workplace satisfaction
Tensioner
Piston
Piston compressors come with an optional belt tensioner. This belt tensioner allows for quick and easy belt tightening. It features a double bolt tension device that keeps the belts perfectly aligned—no pry bars needed!
Rotary
All Rotary Screw belt-driven models (5HP – 20HP) include an automatic spring-loaded belt tensioning device, maintaining optimal belt tension.
Auto Drain
Operation
A dual timer electric auto drain is designed to expel moisture and water from the air receiver tank.
Interval Setting Feature
This feature allows you to set drain cycles from 1 to 45 minutes and control how long the drain remains open.
Muffler Included
Our premium series compressors include an air muffler for quiet water dispersion.
Belt Drive
Our belt-driven compressors use V-belts, allowing for adjustable pump speeds by changing pulley sizes.
Piston Warranty
Eaton Compressor backs all our piston air compressors with the best extended warranty in the industry. We don’t require a service plan—just the purchase and use of our oil and filters to ensure proper maintenance. We offer three extended warranty options so you can choose the best fit for your company. Our trained service and support team is always available, and we carry a full line of air compressor replacement parts.
Tech Specs
| Specification | Details |
|---|---|
| Brands | EMAX |
| HP | 15 |
| Tank Size | 120 |
| Voltage +/- 10% | 460 |
| Phase | 3 |
| Drive Type | Electric |
| Tank Drain | Automatic |
| Pump Type | Pressure |
| CFM | 58 |
| Silent Air | Y |
| Smart Air | N |
| Compressor Type | Piston |
| Motor Type | TEFC |
| Tank Orientation | Vertical |
| Duty Cycle | 0.6 |
| Outlet Size | 1" |
| Belt Count | 2 |
| Pump Stage | 2 |
| Pump Model | APP3Y2062TP |
| Pump Riser | Y |
| Belt Tensioner | Y |
| Mag Starter | Y |
| Radiator | N |
| Continuous Run | Y |
| Peak Starting Amps | 118 |
| CFM At Max PSI | 52 |
| Pump RPM | 815 |
| Motor RPM | 1740 |
| FLA + 1.15 Service Factor | 20.9 |
| Locked Rotor Amps | 118 |
| Recommended Breaker | 35 |
| Max PSI | 175 |
| Uncrated Weight | 1131 lbs |
| Crated Weight | 1280 lbs |
| Crated Length | 48" |
| Crated Width | 46" |
| Oil Capacity | 3 |
| Oil U/M | Quarts |
| Start Type | FIXED |
| Estimated Pump Life (Hours) | 70000 |
| Certifications | ETL, ASME, CRN |
| Service Kit | EFKIT009AWB |
