·Chills the air to condense & remove moisture; runs on 460 Volt, 3-phase
·230 PSI max; max inlet temp: 150°F; 37°F - 50°F dewpoint; designed for 3" pipe
·Max ambient temperature: 120°F; for use with compressors that do not have aftercoolers
·5 Micron Pre-Filter
·Removes larger dust & dirt particles from the air supply so the dryer can work more efficiently
·1 Micron Active Coalescing Filter
·Removes oil & water particles from the air; cleaner, drier air improves tool life & project results
·Refrigerated Air Inlet Inner Cooler
·Trouble-free high temperature cooling for consistent, dry air
·Automatic Drain System
·Eliminates the need for daily maintenance
·Outlet Air Baffle Heater
·Prevents condensation on outlet air piping
·Side Mounted Condenser & Fan Motor
·Easy to reach & service through the cabinet doors - no screws to slow you down
·Uses environmentally friendly R134A refrigerant
·Heavy Duty Steel Cabinet & Safety Shut-Off Valve
·Meets the demands of industrial use; valve shuts the compressor down if it gets over or below a safe temperature
·2 Year Limited Factory Warranty; 5 Years On Heat Exchanger
Air Compressor Accessories Specifications
Specification
Value
Product Category
Air Compressor Accessories
Air Dryer Voltage
460V 3-Phase
Air Dryer CFM
575
Max PSI
230
Max Inlet Temp. Rating
150
Max Ambient Temp. Rating
120
Non-Cycling
Yes
Inlet Fittings
3"
Outlet Fittings
3"
Aftercooler
No
Pre-Filter
Yes
Post-Filter
Yes
Wall Mountable
No
Alarm Lights
No
Auto Drain
Yes
Regenerative
No
Rated HP
125
Dryer Magnetic Starter
Yes
Dry Amp Draw
10
Weight
500 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
27 Inches
Product Width
31 Inches
Product Height
55 Inches
Power Type
Electric
UPC
815002013855
