THE CLEMCO PULSAR III SUCTION CABINET Is The First Industrial, All-In-One Blast System To Include A True Media Reclaimer And Modern Reverse Pulse Cartridge Dust Collector. Fully Equipped To Handle Most Common Recyclable Blast Medias, And Its Compact Size Makes It The Right Unit When Space Is Limited.
Each Pulsar Component Has Been Engineered TO Work In Balance With The Whole System. Capacities For The Sump, Reclaimer, Dust Collector, And Blast System Are Perfectly Matched. Because The Components Are Housed In One Cabinet, Routing Of Hoses And Tubes Is Simple And Direct. The Result Is A Cabinet That's Easy To Install, Easy To Use, And Easy To Maintain.
We Build Pulsar Cabinets To Stand Up To Years Of Heavy Industrial Use. The Blast Enclosure And Support Structure Are Made From 14-Gauge Steel. Formed-In-Place Stress Members Prevent Cabinet Warping And Buckling.
The Double-Wall, Sound-Insulated Doors And The Door Frame, Form An Edge Baffle And Positive Seat To Prevent The Escape Of Dust And Abrasive.
Side Access Allows Easy Adjustments And Maintenance. Emptying The Dust Drum Or Replacing The Filer Cartridge Takes Just Minutes. Side Access Puts The Reclaimer Door, The Metering Valve, The Moisture Separator, And The Pulse Pressure Regulator With Gauge At Your Fingertips.
Pulsar Controls Are Conveniently Located Within The Operator's Reach. The Operator Can Easily Adjust Air Pressure While Blasting To Suit The Application. The Cabinet-Top-Mounted Light Module Creates Full-View, Uniform Lighting Inside The Cabinet, And Is Easily Serviced. Tilt-Out Window Allows Tool-Free Window Replacement In Minutes. Positive Latches Pull The Doors Closed Tight. Lift-Off Hinges Allow You To Swap The Standard Door For A Pass-Through Door, A Vestibule Door, Or A door Fitted With Our Tumble Basket. All Are Available Through Clemco's Options Plus Program.
With The Standard Pulsar Installed Reverse Pulse Cartridge Dust Collector Each Time The Pedal Is Pressed Or Released, A Pulse Of Compressed Air Knocks Caked-On Dust Off The Cartridge And Into The Dust Drum. The Dust Collector Cartridge Traps More Than 99.7% Of The Dust Particles Down TO 0.5 Micron. If Cabinet Visibility Decreases, A Few Press-And-Release Cycles Quickly Clean The Filter Cartridge. The Long-Lasting Cartridges Can Be Replaced In Minutes, Reducing Downtime. Pulsar's Pulse Valve Has Its Own Pressure Regulator And Gauge.All Pulsars Come Equipped With The ZERO Reclaimer To Handle Most Common Recyclable
Blast Media, From Glass Bead To Coarse Aluminum Oxide. It Efficiently Separates Dust And Debris From Reusable Media. The Reclaimer Incorporates A Wear-Plate Which Protects The Inlet From Damage By Debris. The Large Basket Beneath The Reclaimer Screens Out Oversize Material That Can Clog The Blast System. A Fully Adjustable Metering System Delivers As Much Or As Little Media As Needed.
CLEMCO Pulsar III Zero Suction Blast Cabinet Features & Specifications:
- Overall Dimensions:Height: 76" Width: 38" Depth: 62"
- Working Dimensions: Height: 37" Width: 36" Depth: 35"
- L/R Side Door: 34" x 32.5"
- Window: 19.5" x 12.5" Safety Glass With Quick-Change Frame
- Construction: 14 Gauge Steel
- Gun Assembly: Foot Operated: 25 CFM @ 90-100 PSI
- Electrical: 1/2 HP, 115 Volt, Single Phase
- Dust Collector: Reverse Pulse Cartridge Dust Collector
- Rubber Cloth-Lined Gloves
- Two Tube Fluorescent Light Fixture
- Dust-Off Gun
- Pneumatic Foot-Treadle Control
- Air Pressure Regulator & Gauge
- General Purpose Air Filter
- Media Regulator
- 300 CFM Media Reclaimer
- Patented OSHA Door Interlocks
- Ventilation Area: 107 Square Feet
- Shipping Weight: 800 Lbs.
