The Baileigh WBS-37H is the 460V/3-phase version of Baileigh’s 37" x 60" wide belt sander, built for fabrication, precision machining, and MRO shops running higher-voltage service. Its 10 HP main motor and 1720 RPM belt drive produce up to 2,700 FPM of abrasive belt speed , and the variable 2–26 FPM conveyor handles material from 1/32" to 6" thick and up to 37" wide. Auto sanding height adjustment, a digital readout, and 10 programmable height presets simplify repeat setups, while auto belt tracking keeps the abrasive centered to extend belt life. UL 987-certified door interlocks, an E-stop, and a quick-stop abrasive belt e-brake protect operators, and the machine carries a 1-year parts warranty plus Baileigh Lifetime Technical Support. Industries & Who It's For MRO Typical work: Removing corrosion and weld spatter, finishing refurbished parts on 460V equipment. What they need: Needs durability, reliability, low setup time, and quick availability. Industries: Marine, Oil & Gas, Power Generation, Rail Fabrication Typical work: Removing slag, radiusing edges, cleaning oxide, prepping for paint or coating. What they need: Needs throughput, labor reduction, and the ability to run mixed materials. Industries: Construction, Agriculture, Appliance Mfg, HVAC Precision Machining Typical work: Removing burrs after machining, applying a consistent surface finish, prepping for coating. What they need: Needs accurate dimensional control and a repeatable finish. Industries: Aerospace, Medical Devices, Automotive, Electronics, Defense Common Applications • Precision grinding: removing material to meet tight tolerances ahead of painting or coating. • Heavy slag removal: producing a uniform, rounded edge on flame- or plasma-cut parts. • Finishing: polishing sheet metal or workpieces to a durable surface prior to assembly. • Deburring: removing burrs from parts cut on plasma tables, laser tables, waterjets, and similar equipment. Works with: Mild Steel, Stainless Steel, Non-Ferrous Metals, Plastics Warranty & Support: 1-year parts warranty plus Baileigh Lifetime Technical Support
Features
- 460V/3-phase motor suits higher-voltage shop electrical service
- 10 HP main motor and 37" x 60" belt handle large workpieces and heavy stock removal
- Auto sanding height adjustment with 10 programmable presets speeds repeat changeovers
- Auto belt tracking keeps the abrasive centered, reducing uneven wear and downtime
- Variable 2-26 FPM conveyor and 1/32"-6" thickness range adapt to a wide range of parts
- UL 987-certified door interlocks, E-stop, and quick-stop abrasive belt e-brake protect operators
- 5" dust port mounts overhead to a Baileigh dust collector for efficient chip removal
- Well suited to deburring, slag removal, and surface finishing across mixed metal materials
- 1-year parts warranty plus Baileigh Lifetime Technical Support for long-term uptime
| Specifications | |
|---|---|
| Abrasive Type | Belt |
| Assembled Dimensions | 65.9" x 52.4" x 73.8" |
| Belt Size | 37 in. x 60 in. |
| Belt Speed | 1720 FPM |
| Conveyor Gear Box Ratio | 1/100 |
| Conveyor Motor (HP) | 1/4 hp |
| Conveyor Speed | 2 - 16 FPM Variable Speed |
| Country of Origin | Taiwan |
| Dust Port Outside Diameter | 5 in. |
| Horse Power | 10 |
| Infeed Table Length | 19.3 in. |
| Maximum Material Width | 37 in. |
| Minimum Material Length | 8" |
| Minimum Material Thickness | 1/32" |
| Model Number | WBS-37H |
| Motor Amps | 25 |
| Number of Belt Speeds | 1 |
| Warranty | 1 Year |
| Motor HP | 10 |
| Motor Phase | Three |
| Motor Voltage | 460 |
