The Delco® CWE Portable Series DWM1330042B (part 65171) is a 230V electric cold water pressure washer built on a small steel wall-mount frame. It delivers 1300 PSI at 3.0 GPM (3,900 cleaning units) from a 3HP, 230V, single-phase, 13.2A motor. A direct-drive UDOR® industrial triplex pump handles high-temperature water feed up to 165° F. With an enclosed cabinet-style design and simple operation, it suits shops, wash bays and facilities that want a fixed, ready-to-use cleaning station.
Performance & Power
- 1300 PSI at 3.0 GPM for 3,900 cleaning units
- 3HP / 230V / 1-phase / 13.2A electric motor
- Automatic start/stop feature
- Built-in hour meter
- High-temperature water feed, capable up to 165° F
UDOR® Industrial Triplex Pump
- Direct-drive UDOR® industrial triplex pump
- Forged brass manifold
- Ceramic-coated plunger sleeves
- Thermal relief valve
- External unloader with bypass hose
Frame & Design
- Small wall-mount steel frame, 250 lbs
- Wall mount bracket comes standard with part 65171
- Powder-coated steel frame for corrosion resistance
- Steel powder-coated panel cover
- Dimensions: L 32" x W 16" x H 14"
- Optional accessory: Remote Box (Small Frame), part 80650
Included Equipment
- 3/8" x 50' steel-braided Armor Hose®
- Trigger gun and lance
- Quick-connect nozzles: 15°, 25°, 40° and soap
- Downstream injector
Warranty
- 10-Year Frame, 5-Year Pump, 1-Year Motor
Have questions about the Delco DWM1330042B, installation, or accessories? Call Pittsburgh Spray Equipment at 888-714-1410. Our team is happy to help you choose the right setup.
Specifications
| Model | DWM1330042B |
| Part Number | 65171 |
| Series | CWE Portable |
| Pressure | 1300 PSI |
| Flow | 3.0 GPM |
| Cleaning Units | 3,900 |
| Motor | 3HP / 230V / 1-phase / 13.2A |
| Water | Cold water (feed up to 165° F) |
| Pump | UDOR® industrial triplex |
| Drive | Direct |
| Frame | Small Wall Mount / Steel |
| Weight | 250 lbs |
| Dimensions | L 32" x W 16" x H 14" |
| Hose | 3/8" x 50' steel-braided Armor Hose® |
| Warranty | 10-Year Frame, 5-Year Pump, 1-Year Motor |
