FEATURES
-
Professional quality Honda GX390 engine with electric start drives the pump. A 55 AH Marine battery is included.
-
Direct drive system connects the engine to the pump for a compact and efficient power transfer.
-
Commercial grade Centurion triplex pump featuring die-cast body, forged brass manifold, ceramic plungers, thermal release valve and improved heat dissipation.
-
External unloader provides superior cooling and versatility to further enhance pump life.
-
Heating coil is ignited by a 12 V Beckett that is fueled with diesel and includes a low voltage inhibitor.
-
The burner can be turned off and controlled with the adjustable thermostat that can be set up to 93°C / 200°F.
-
Commercial grade accessories included are a 50′ high pressure hose, spray gun wand assembly, and four spray nozzles.
-
Stainless steel frame with four 13″ flat-free tires for stability and to handle rough terrain. Roll cage design protects the components while allowing easy access to use or maintain.
-
A lift point is built into the frame to allow the use of a crane to lift it onto a truck or trailer.
-
Frame includes mounting brackets for quick installation onto trucks or trailers by removing the wheels.
SPECIFICATIONS
ENGINE
-
Model: Honda GX390
-
Type: Air cooled, 4-stroke OHV
-
Displacement: 389 cc
-
Fuel type: 86 octane, up to 10% ethanol
-
Oil type: SAE 10W30
PUMP SPECS
-
Model: Centurion CTG2S
-
Type: Triplex
-
Part number: 85.120.142
-
Oil type: 30W non-detergent
-
Soap system: Adjustable injector
UNLOADER
-
Type: External
-
Part number: AL607
BURNER
-
Thermostat: On/off and adjustable
-
Max heat: 93°C / 200°F
-
Igniter: 12 V Beckett burner
-
Heating coil: 1/2″ cold rolled steel
-
Coil tube length: 96′ length of tubing
-
Fuel capacity: 10 gal
-
Fuel type: Diesel
ACCESSORIES
-
Hose type: 50′ x 3/8″ twin wire-braided
-
Part number: 85.238.251
-
Nozzles: 15°, 25°, 40° and soaper
-
Part number: 85.210.040H
-
Gun wand: 36″ insulated
-
Part number: 85.205.026
-
Fittings: Quick connect
FRAME
-
Material: Stainless steel
-
Wheels: 13″ flat-free
SHIPPING SIZE
-
L x W x H: 45″ x 33″ x 52″
-
Weight: 580 lb
UNIT SIZE
-
L x W x H: 51″ x 30″ x 46″
-
Weight: 530 lb
WARRANTY
-
Engine: 3 years
-
Pump: 7 years
-
Heating coil: 3 years
-
UPC: 777987417700
