RANSBURG A10960-00 ASS'Y, 4 COLOR VALVE CIRCULATING,ENGLISH
MCV 2 Collet Series Color Changer - Parts Identification
| Item# | Part# | QTY |
| 1 | A10960-00 Assembly, Circulating 4-Color Stac | 1 |
| 2 | 77367-00 Assembly, Valve Seat | 4 |
| 3 | 78949-00 Assembly, Valve | 4 |
| 4 | 77762-05 Collet, 3/8" | 4 |
| 5 | 79001-24 O-Ring, Solvent Proof | 8 |
| 6 | 77762-04 Collet, 5/16" | 4 |
| 7 | 79001-24 O-Ring, Solvent Proof | 8 |
| 8 | 77516-04 Collet, 5/32" | 4 |
| 9 | 79001-30 O-Ring, Solvent Proof | 4 |
| 10 | 79001-06 O-Ring, Solvent Proof | 1 |
| 11 | 79001-05 O-Ring, Solvent Proof | 1 |
| 12 | 77957-00 Retaining Clip, Color Changer | 1 |
| 13 | A10824-00 Red Locking Clip, 3/8” OD Tube | 4 |
| 14 | A10825-00 Red Locking Clip, 1/4” OD Tube | 4 |
