Tee Configured Stainless Steel Model- Medium Volume

Tee Configured Stainless Steel Model- Medium Volume

Regular price
$7,370.00
Sale price
$7,370.00
Quantity must be 1 or more


Dampens Pump Pulsation for Consistent Finish Quality

  • Stainless steel and PTFE materials are compatible with many finishing materials
  • Reduces pulsation for consistent material delivery and uniform spray pattern
  • Isolate the surge tank and perform on-line maintenance with tee configuration
  • High quality design reduces maintenance and charge pressure refills
  • In-line flow configuration is easy to flush, making color changes quick and easy
  • Multiple fluid connection options accommodate global system requirements
UPC Product: 00633955734715
Family Code: FAMCNV
Unit of Measure: EA
Height: 13.2 IN   |  33.528 CM
Length: 18 IN   |  45.72 CM
Width: 18 IN   |  45.72 CM
Volume: 2.48 FT3   |  .07 M3
Chargeable Weight: 31 LBS  | 14.06 KG

Technical Specifications

Inlet Size (cm) 1.905
Inlet Size (in) 3/4
Inlet Size (mm) 19.05
Inlet Thread Type BSPP
Maximum Fluid Pressure (bar) 25
Maximum Fluid Pressure (kPa) 2500
Maximum Fluid Pressure (psi) 360
Outlet Size (cm) 1.905
Outlet Size (in) 3/4
Outlet Size (mm) 19.05
Outlet Thread Type BSPP
Wetted Material Stainless Steel, PTFE
Type Rod
Maximum Fluid Pressure (MPa) 2.5
