Used on MH divider valve applications where lube system pressures exceed 2,500 psi (172 bar).
Feel free to call or chat with us for recommendations.
📦
Ships in 2-3 weeks, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
High pressure from blockage causes a disc to rupture
Lubricant forces an indicator pin to protrude, indicating the blockage
High pressure backs up through the system and trips a switch to shut the system off
When fault is corrected, disc must be replaced and pin reset
- Lubriquip part number 509-499-620
UPC Product: 00633955331594
Family Code: FAMCPT
Unit of Measure: EA
Height:
.6 IN
| 1.524 CM
Length:
1.55 IN
| 3.937 CM
Width:
.6 IN
| 1.524 CM
Volume:
0 FT3
| 0 M3
Chargeable Weight:
.08 LBS
| .04 KG
Technical Specifications
| Application | On-Road Vehicles, Off-Road Equipment |
|---|---|
| Compatible Material | Oil, Grease |
| Connection Size (in) | 0.125 |
| Indicator Type | Rupture Indicator |
| Maximum Working Pressure (bar) | 193 |
| Maximum Working Pressure (kPa) | 19300 |
| Maximum Working Pressure (psi) | 2800 |
| Overall Width (mm) | 14.224 |
| Overall Length (cm) | 4 |
| Overall Length (in) | 1.77 |
| Overall Length (mm) | 45 |
| Overall Width (cm) | 1.4224 |
| Overall Width (in) | 0.56 |
| Thread Type | NPTF |
| Type | Relief Valve |
| Maximum Working Pressure (MPa) | 19.3 |
