By upgrading back-geared agitators with radial piston air motors, factory paint mix rooms can cut compressed air costs by up to 85 percent.
For agitating high viscosity (500 to 3000 cP) material
Feel free to call or chat with us for recommendations.
📦
Ships in 2-3 weeks, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
- Installs quickly for immediate cost savings
- Needs no air line lubrication needed to keep running well
- Operates more quietly than comparable rotary vane agitator air motors
- Connect with Graco’s Intelligent Paint Kitchen (IPK) to monitor and the control agitator speed.
UPC Product: 00769946181616
Family Code: FAMQFP
Unit of Measure: EA
Height:
15.25 IN
| 38.735 CM
Length:
15.25 IN
| 38.735 CM
Width:
12.5 IN
| 31.75 CM
Volume:
1.682 FT3
| .048 M3
Chargeable Weight:
20.4 LBS
| 9.25 KG
Technical Specifications
| Air Inlet Size (cm) | 0.635 |
|---|---|
| Air Inlet Size (in) | 1/4 |
| Air Inlet Size (mm) | 6.35 |
| Air Inlet Thread Type | NPT |
| For Use With | 55 加仑（208 升）料桶, 55 Gallon (208 Liter) Drum, 208 litre (55 gallon) drum, Fût de 208 litres (55 gallons), Bidón de 55 galones (208 litros), Fass mit 208 Litern (55 Gallonen), 55 gallon (208 liter) vat |
| Maximum Air Inlet Pressure (bar) | 5 |
| Maximum Air Inlet Pressure (kPa) | 500 |
| Maximum Air Inlet Pressure (psi) | 70 |
| Maximum Speed (RPM) | 83 |
| Maximum Viscosity (cP) | 3000 |
| Maximum Working Pressure (bar) | 5 |
| Maximum Working Pressure (kPa) | 500 |
| Maximum Working Pressure (psi) | 70 |
| Motor Type | Pneumatic - Radial Piston |
| Power Rating (HP) | 0.16 |
| Weight (kg) | 14.1 |
| Weight (lb) | 31.1 |
| Wetted Material | Stainless Steel, Acetal, AF, Nylon, PTFE |
| Type | Conversion Kit |
