Polypropylene Twistork Husky Pump

Polypropylene Twistork Husky Pump

Regular price
$5,230.00
Sale price
$5,230.00
Quantity must be 1 or more


The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

  • Benefits of the Husky 515 double diaphragm pump

    • Center and end porting options.
    • No mechanical seals to cause fluid leaks or failures
    • Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
    • Easy-to-service air valve and ball checks
    • Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
    • Split manifold option to pump multiple fluids without mixing
  • Fully-groundable acetal model
  • Delivery up to 15 gpm (56.7 lpm)
  • Easy-to-service air valve and ball checks
  • Reliable air valve for years of dependable performance
UPC Product: 00633955719859
Family Code: FAMAOD
Unit of Measure: EA
Height: 16.8 IN   |  42.672 CM
Length: 66 IN   |  167.64 CM
Width: 15.6 IN   |  39.624 CM
Volume: 10.01 FT3   |  .283 M3
Chargeable Weight: 104.201 LBS  | 47.242 KG

Technical Specifications

Maximum Operating Temperature (°F) 150
Maximum Working Pressure (bar) 7
Maximum Working Pressure (kPa) 700
Maximum Working Pressure (psi) 100
Type Diaphragm Pump Package
Manifold Configuration Split Port
Material Polypropylene
Model Husky
Series 515
