1:1 Ratio Stainless Steel MD2 Valve with Hard Seat

1:1 Ratio Stainless Steel MD2 Valve with Hard Seat

Regular price
$5,760.00
Sale price
$5,760.00
Quantity must be 1 or more


Accurately dispenses and mixes two-component sealants and adhesives

  • Adjustable Snuff-back Control

    • Dispenses material only where you need it
  • Independent Air Cylinder

    • Improves mean time to repair (MTTR)
  • Chromex™ Shafts

    • Extends shaft life to better handle abrasive materials
  • Grease Isolation Chamber

    • Ideal for moisture-sensitive materials
    • Accessible grease fittings for easy maintenance
  • Adjustable Inlet Position

    • Flexibility during system installation
    • Minimizes dead spaces in fluid path
  • All-SST Wetted Section

    • Maximizes material compatibility
  • Two Nose Options

    • Customizes material mixing
  • Minimizes maintenance time and costs while maximizing dispense time

  • Designed with fewer parts and is easy to clean

  • Streamlines maintenance and service

UPC Product: 00755652410867
Family Code: FAMOMA
Unit of Measure: EA
Height: 4.9 IN   |  12.446 CM
Length: 9.7 IN   |  24.638 CM
Width: 8.1 IN   |  20.574 CM
Volume: .223 FT3   |  .006 M3
Chargeable Weight: 2.75 LBS  | 1.25 KG

Technical Specifications

Type 2 Component Static Mix Valve
For Use With 2 Component Meter Mix Dispense Systems
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20700
Maximum Working Pressure (MPa) 20.7
Maximum Working Pressure (psi) 3000
Nozzle Size (cm) 0.875
Nozzle Size (in) 0.345
Nozzle Size (mm) 8.758
Number of Outputs 2
Model MD2

;
