RANSBURG A11206-01 REAR MANIFOLD PLATE EVOLVER 303 SINGLE PURGE
| Item # | Part# - Description | Qty |
| 1 | A11205-00 Assembly, Plate, Rear RMA-303 Single Purge | 1 |
| 2 | 79001-40 O-Ring, Solvent Proof | 4** |
| 3 | 79001-39 O-Ring, Solvent Proof | 2** |
| 4 | 77507-00 Air Stud, Small Machined | 3* |
| 5 | 79001-05 O-Ring, Solvent Proof | 3** |
| 6 | 77506-00 Air Stud, Medium Machined | 1* |
| 7 | 79001-06 O-Ring, Solvent Proof | 2** |
| 8 | 77505-00 Air Stud, Large | 3* |
| 9 | 79001-07 O-Ring, Solvent Proof | 3** |
| 10 | SSF-2052 Set Screw, 3/8" Lg X #10-24 | 2 |
| 11 | 79001-09 O-Ring, Solvent Proof | 1** |
| 12 | A12035-00 Air Stud, Medium, Machined, Evolver 303 | 1* |
*Apply thread sealer 7969-10 to threads prior to assembly.
**Apply a thin film of SSL-11 petroleum jelly to o-rings before assembly
**Apply a thin film of SSL-11 petroleum jelly to o-rings before assembly
