RANSBURG A10955-00 ASS'Y, 2 COLOR VALVE DEAD HEAD ENGLISH
MCV 2 Collet Series Color Changer - Parts Identification
| Item# | Part# | QTY |
| 1 | A10956-02 Assembly, 2-Color Dead Head (Metric) | 1 |
| 2 | 77367-00 Assembly, Valve Seat | 2 |
| 3 | 78949-00 Assembly, Valve | 2 |
| 4 | 77762-05 Collet, 3/8" | 2 |
| 5 | 79001-24 O-Ring, Solvent Proof | 4 |
| 6 | 77516-04 Collet, 4mm | 2 |
| 7 | 79001-30 O-Ring, Solvent Proof | 2 |
| 8 | 79001-06 O-Ring, Solvent Proof | 1 |
| 9 | 79001-05 O-Ring, Solvent Proof | 1 |
| 10 | 77957-00 Retaining Clip, Color Changer | 1 |
| 11 | A10824-00 Red Locking Clip, 3/8” OD Tube | 2 |
