RANSBURG A10727-00 ASS'Y, 2 COLOR PTL CIRCULATING (METRIC)
MCV 2 Collet Series Color Changer - Parts Identification
| Item# | Part# | Description | QTY |
| 1 | A10734-01 | Assembly, 2-Color Valve Circulating | 1 |
| 2 | 77367-00 | Assembly, Valve Seat | 2 |
| 3 | 78949-00 | Assembly, Valve | 2 |
| 4 | 77762-02 | Collet, 10mm | 2 |
| 5 | 79001-31 | O-Ring, Solvent Proof | 4 |
| 6 | 77762-04 | Collet, 8mm | 2 |
| 7 | 79001-34 | O-Ring, Solvent Proof | 4 |
| 8 | 77516-04 | Collet, 4mm | 2 |
| 9 | 79001-30 | O-Ring, Solvent Proof | 2 |
| 10 | 79001-06 | O-Ring, Solvent Proof | 1 |
| 11 | 76001-05 | O-Ring, Solvent Proof | 1 |
| 12 | 77957-00 | Retaining Clip, Color Changer | 1 |
| 13 | A10824-00 | Red Locking Clip, 3/8” OD Tube | 2 |
| 14 | A10825-00 | Red Locking Clip, 1/4” OD Tube | 2 |
