Limits the supply pressure to a set value by opening an outlet and guiding back excess material when the predetermined pressure has been achieved. Used in circulating systems.
Feel free to call or chat with us for recommendations.
📦
Ships in 2-3 weeks, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
UPC Product: 00633955858527
Family Code: FAMCNV
Unit of Measure: EA
Height:
6 IN
| 15.24 CM
Length:
10.8 IN
| 27.432 CM
Width:
9.6 IN
| 24.384 CM
Volume:
.36 FT3
| .01 M3
Chargeable Weight:
4.17 LBS
| 1.89 KG
Technical Specifications
| Gauge Port Size (cm) | 0.3175 |
|---|---|
| Gauge Port Size (in) | 1/8 |
| Gauge Port Size (mm) | 3.175 |
| Gauge Port Type | BSPP |
| Includes | Regulator Only, Solo regulador |
| Inlet Size (cm) | 0.9525 |
| Inlet Size (in) | 3/8 |
| Inlet Size (mm) | 9.525 |
| Inlet Thread Type | BSPP |
| Maximum Flow Rate (GPM) | 5.7 |
| Maximum Flow Rate (L/min) | 21.7 |
| Maximum Operating Temperature (°C) | 90 |
| Maximum Operating Temperature (°F) | 194 |
| Maximum Regulated Pressure (bar) | 20 |
| Maximum Regulated Pressure (kPa) | 2000 |
| Maximum Regulated Pressure (psi) | 290 |
| Maximum Working Pressure (bar) | 20 |
| Maximum Working Pressure (kPa) | 2000 |
| Maximum Working Pressure (psi) | 290 |
| Minimum Operating Temperature (°C) | 0 |
| Minimum Operating Temperature (°F) | 32 |
| Minimum Regulated Pressure (bar) | 1 |
| Minimum Regulated Pressure (kPa) | 100 |
| Minimum Regulated Pressure (psi) | 15 |
| Outlet Size (cm) | 0.9525 |
| Outlet Size (in) | 3/8 |
| Outlet Size (mm) | 9.525 |
| Outlet Thread Type | BSPP |
| Wetted Material | Stainless Steel, Tungsten Carbide, PTFE, Chemically Resistant Fluoroelastomer |
| Type | Back Pressure Regulator |
| Minimum Regulated Pressure (MPa) | 0.1 |
