Designed with electroplated surfaces that prevent debris build-up and keep your operation free of contaminants, Graco pressure pots are precision welded and surfaced.
Feel free to call or chat with us for recommendations.
📦
Ships in 2-3 weeks, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
- ASME rated to ensure it meets factory standards
- High quality stainless steel design is compatible with many materials
- Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir
UPC Product: 00633955199682
Family Code: FAMCNV
Unit of Measure: EA
Height:
27.6 IN
| 70.104 CM
Length:
15.6 IN
| 39.624 CM
Width:
15.6 IN
| 39.624 CM
Volume:
3.887 FT3
| .11 M3
Chargeable Weight:
40.463 LBS
| 18.345 KG
Technical Specifications
| Inlet Size (cm) | 0.635 |
|---|---|
| Inlet Size (in) | 1/4 |
| Inlet Size (mm) | 6.35 |
| Inlet Thread Type | NPT |
| Maximum Volume Capacity (gal) | 2 |
| Maximum Volume Capacity (L) | 8 |
| Maximum Working Pressure (bar) | 7 |
| Maximum Working Pressure (kPa) | 700 |
| Maximum Working Pressure (psi) | 100 |
| Outlet Size (cm) | 0.9525 |
| Outlet Size (in) | 3/8 |
| Outlet Size (mm) | 9.525 |
| Outlet Thread Type | NPSM |
| Overall Height (cm) | 64.5 |
| Overall Height (in) | 25.4 |
| Overall Height (mm) | 645 |
| Overall Width (cm) | 33.3 |
| Overall Width (in) | 13.125 |
| Overall Width (mm) | 333 |
| Weight (kg) | 13.7 |
| Weight (lb) | 30.25 |
| Wetted Material | Stainless Steel, Polypropylene, Santoprene |
| Inlet Thread Gender | Male |
| Outlet Thread Gender | Male |
| Maximum Working Pressure (MPa) | 0.7 |
