Stainless Steel High Pressure Fluid Gauge, 0-68 bar (0-1000 psi) pressure range

Stainless Steel High Pressure Fluid Gauge, 0-68 bar (0-1000 psi) pressure range

Regular price
$200.50
Sale price
$200.50
Quantity must be 1 or more


Feel free to call or chat with us for recommendations.

📦 Ships in 6-10 days, shipping times may vary
🚚 Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁 30-day returns. Click here for more info.

  • Stainless Steel High Pressure Fluid Gauges

    • Corrosion-resistant
    • 63 mm (2.5 in) diameter dial
    • 1/4 in npt(m) connection
    • Bottom mount
    • Shatter-proof glass
    • Liquid filled to reduce indicator pulsation
UPC Product: 00633955559165
Family Code: FAMQFP
Unit of Measure: EA
Height: 1.8 IN   |  4.572 CM
Length: 3.2 IN   |  8.128 CM
Width: 3.6 IN   |  9.144 CM
Volume: .012 FT3   |  0 M3
Chargeable Weight: .55 LBS  | .25 KG

Technical Specifications

Dial Diameter (cm) 6
Dial Diameter (in) 2.5
Dial Diameter (mm) 64
Inlet Size (cm) 0.635
Inlet Size (in) 1/4
Inlet Size (mm) 6.35
Inlet Thread Gender Male
Inlet Thread Type NPT
Material Stainless Steel
Maximum Working Pressure (bar) 69
Maximum Working Pressure (kPa) 6900
Maximum Working Pressure (psi) 1000
Type Pressure Gauge
Maximum Working Pressure (MPa) 6.9
