Mechanical Back Pressure Regulator, 3400 psi max permanent supply pressure, 1300-3000 psi pressure range

Mechanical Back Pressure Regulator, 3400 psi max permanent supply pressure, 1300-3000 psi pressure range

Regular price
$1,460.00
Sale price
$1,460.00
Quantity must be 1 or more


For use in air-assisted spray systems to ensure accurate, positive control of fluid pressure to a spray gun, dispensing valve, or atomizing head.

UPC Product: 00633955803671
Family Code: FAMCNV
Unit of Measure: EA
Height: 6 IN   |  15.24 CM
Length: 9.6 IN   |  24.384 CM
Width: 8.4 IN   |  21.336 CM
Volume: .28 FT3   |  .008 M3
Chargeable Weight: 2.915 LBS  | 1.322 KG

Technical Specifications

Gauge Port Size (cm) 0.635
Gauge Port Size (in) 1/4
Gauge Port Size (mm) 6.35
Gauge Port Type BSPP
Includes Regulator Only, Solo regulador
Inlet Size (cm) 0.9525
Inlet Size (in) 3/8
Inlet Size (mm) 9.525
Inlet Thread Type BSPP
Maximum Flow Rate (GPM) 13.1
Maximum Flow Rate (L/min) 49.8
Maximum Operating Temperature (°C) 90
Maximum Operating Temperature (°F) 194
Maximum Regulated Pressure (bar) 207
Maximum Regulated Pressure (kPa) 20700
Maximum Regulated Pressure (psi) 3000
Maximum Working Pressure (bar) 235
Maximum Working Pressure (kPa) 23500
Maximum Working Pressure (psi) 3400
Minimum Operating Temperature (°C) 0
Minimum Operating Temperature (°F) 32
Minimum Regulated Pressure (bar) 90
Minimum Regulated Pressure (kPa) 9000
Minimum Regulated Pressure (psi) 1300
Outlet Size (cm) 0.9525
Outlet Size (in) 3/8
Outlet Size (mm) 9.525
Outlet Thread Type BSPP
Wetted Material Stainless Steel, Tungsten Carbide, PTFE, Chemically Resistant Fluoroelastomer
Type Back Pressure Regulator
Minimum Regulated Pressure (MPa) 9
