Low Pressure Air Gauge, back mount, 0-7 bar (0-100 psi) pressure range

Low Pressure Air Gauge, back mount, 0-7 bar (0-100 psi) pressure range

Regular price
$53.00
Sale price
$53.00
Quantity must be 1 or more


  • Low Pressure Air Gauges

    • Black enamel case
    • Back mount
    • 1/8 in NPT and 1/4 in NPT connections
  • Back mount
UPC Product: 00633955307438
Family Code: FAMQFP
Unit of Measure: EA
Height: 2.1 IN   |  5.334 CM
Length: 1.85 IN   |  4.699 CM
Width: 1.85 IN   |  4.699 CM
Volume: .004 FT3   |  0 M3
Chargeable Weight: .16 LBS  | .07 KG

Technical Specifications

Dial Diameter (cm) 4
Dial Diameter (in) 1.5
Dial Diameter (mm) 38
Inlet Size (cm) 0.3175
Inlet Size (in) 1/8
Inlet Size (mm) 3.175
Inlet Thread Gender Male
Inlet Thread Type NPT
Maximum Working Pressure (bar) 7
Maximum Working Pressure (kPa) 700
Maximum Working Pressure (psi) 100
Type Pressure Gauge
Maximum Working Pressure (MPa) 0.7
