Graco Balancing Valve, 1/8-27

Graco Balancing Valve, 1/8-27

Regular price
$537.00
Sale price
$537.00
Quantity must be 1 or more


Feel free to call or chat with us for recommendations.

📦 Ships in 2-3 weeks, shipping times may vary
🚚 Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁 30-day returns. Click here for more info.

  • Lubriquip part number 509-510-000
  • Trabon part number 9510
UPC Product: 633955350878
Family Code: FAMMAN
Unit of Measure: EA
Height: 2.1 IN   |  5.334 CM
Length: 5.969 CM   |  2.35 IN
Width: 4.1 IN   |  10.414 CM
Volume: .012 FT3   |  0 M3
Chargeable Weight: 1.17 LBS  | .53 KG

Technical Specifications

Adjustable Adjustable
Compatible Material Oil
Inlet Size (cm) 0.3175
Inlet Size (in) 1/8
Inlet Size (mm) 3.175
Inlet Thread Type NPSF
Material Steel
Maximum Working Pressure (bar) 448
Maximum Working Pressure (kPa) 44800
Maximum Working Pressure (psi) 6500
Outlet Size (cm) 0.3175
Outlet Size (in) 1/8
Outlet Size (mm) 3.175
Outlet Thread Type NPSF
Overall Height (cm) 3.81
Overall Height (in) 1.5
Overall Height (mm) 38.1
Overall Length (cm) 10
Overall Length (in) 3.834
Overall Length (mm) 97
Overall Width (cm) 2.54
Overall Width (in) 1
Overall Width (mm) 25.4
Seal Material Viton
Type Balancing Valve
Maximum Working Pressure (MPa) 44.8
