Keep your machine running while lubrication gets to critical points. These performance indicators pinpoint lube line blockages but allow the lube system to continue to supply lubrication to points that are not blocked.
Feel free to call or chat with us for recommendations.
📦
Ships in 6-10 days, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
- No time or effort required for reset after blockage is cleared
- Easy information on blocked lines, high system pressure or blocked bearings
- Works with MSP, MX, MXP, MJ and MHH divider valves
- Lubriquip part number 508-210-100
UPC Product: 633955350427
Family Code: FAMCPT
Unit of Measure: EA
Height:
.6 IN
| 1.524 CM
Length:
1.524 CM
| .6 IN
Width:
1.3 IN
| 3.302 CM
Volume:
0 FT3
| 0 M3
Chargeable Weight:
.07 LBS
| .03 KG
Technical Specifications
| Application | In-Plant Machinery, Off-Road Equipment, Compressor Equipment |
|---|---|
| Compatible Material | Oil, Grease |
| Connection Size (in) | 0.25 |
| Indicator Type | Automatic Relief Indicators |
| Maximum Working Pressure (bar) | 69 |
| Maximum Working Pressure (kPa) | 6900 |
| Maximum Working Pressure (psi) | 1000 |
| Overall Length (cm) | 3 |
| Overall Length (in) | 1.37 |
| Overall Length (mm) | 35 |
| Thread Type | NPTF |
| Type | Relief Valve |
| Maximum Working Pressure (MPa) | 7 |
| Model | Trabon |
