Viscount Hydraulic Motor with Dura-Flo 2400 (580 cc) Lower, 3 UHMWPE/2 PTFE Packings

Viscount Hydraulic Motor with Dura-Flo 2400 (580 cc) Lower, 3 UHMWPE/2 PTFE Packings

Regular price
$24,210.00
Sale price
$24,210.00
Quantity must be 1 or more


The rugged pump lower construction with Severe Duty rods and cylinders reduces downtime and extends the interval between repairs. The simple construction makes service and repair fast and easy. The efficient hydraulic powered piston makes these pumps the ideal choice for factory and outdoor mobile use, even at below freezing temperatures.

  • Clean, quiet operation with no airborne contamination
  • Up to three times more energy efficient than comparable compressed air systems
  • Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
  • Reduce routine maintenance and cut repairs time in half of comparable pump lowers
  • Eliminate downtime without ice build-up
UPC Product: 00633955072060
Family Code: FAMCPP
Unit of Measure: EA
Height: 16.8 IN   |  42.672 CM
Length: 61.2 IN   |  155.448 CM
Width: 15.6 IN   |  39.624 CM
Volume: 9.282 FT3   |  .263 M3
Chargeable Weight: 250 LBS  | 113.4 KG

Technical Specifications

Type Hydraulic Piston Pump
Application Supply
Compatible Material Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish
Fluid Inlet Size (in) 2
Fluid Inlet Size (mm) 50.8
Fluid Inlet Thread Gender Female
Fluid Inlet Thread Type NPT
Fluid Outlet Size (in) 1-1/2
Fluid Outlet Size (mm) 38.1
Fluid Outlet Thread Gender Male
Fluid Outlet Thread Type NPT
Fluid Section Type 2-Ball
Material Stainless Steel
Maximum Flow Rate (GPM) 9.2
Maximum Flow Rate (L/min) 34.83
Maximum Hydraulic Fluid Inlet Pressure (bar) 103
Maximum Hydraulic Fluid Inlet Pressure (kPa) 10300
Maximum Hydraulic Fluid Inlet Pressure (psi) 1500
Maximum Intermittent Cycle Rate (CPM) 60
Maximum Operating Temperature (°C) 66
Maximum Operating Temperature (°F) 150
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20700
Maximum Working Pressure (psi) 3000
Model Viscount
Portable Non-Portable
Pump Ratio 20:1
Series II
Wetted Material Stainless Steel
Maximum Working Pressure (MPa) 20.7

;
