Mechanical Back Pressure Regulator, 145 psi max permanent supply pressure, 14-145 psi pressure range

Mechanical Back Pressure Regulator, 145 psi max permanent supply pressure, 14-145 psi pressure range

Regular price
$2,700.00
Sale price
$2,700.00
Quantity must be 1 or more


For use in air-assisted spray systems to ensure accurate, positive control of fluid pressure to a spray gun, low pressure dispensing valve, or atomizing head.

UPC Product: 00633955808522
Family Code: FAMCNV
Unit of Measure: EA
Height: 6 IN   |  15.24 CM
Length: 9.6 IN   |  24.384 CM
Width: 6.9 IN   |  17.526 CM
Volume: .23 FT3   |  .007 M3
Chargeable Weight: 4 LBS  | 1.81 KG

Technical Specifications

Gauge Port Size (cm) 0.3175
Gauge Port Size (in) 1/8
Gauge Port Size (mm) 3.175
Gauge Port Type BSPP
Includes Regulator Only, Solo regulador
Inlet Size (cm) 0.9525
Inlet Size (in) 3/8
Inlet Size (mm) 9.525
Inlet Thread Type BSPP
Maximum Flow Rate (GPM) 4.6
Maximum Flow Rate (L/min) 17.5
Maximum Operating Temperature (°C) 90
Maximum Operating Temperature (°F) 194
Maximum Regulated Pressure (bar) 10
Maximum Regulated Pressure (kPa) 1000
Maximum Regulated Pressure (psi) 145
Maximum Working Pressure (bar) 10
Maximum Working Pressure (kPa) 1000
Maximum Working Pressure (psi) 145
Minimum Operating Temperature (°C) 0
Minimum Operating Temperature (°F) 32
Minimum Regulated Pressure (bar) 1
Minimum Regulated Pressure (kPa) 100
Minimum Regulated Pressure (psi) 15
Outlet Size (cm) 0.9525
Outlet Size (in) 3/8
Outlet Size (mm) 9.525
Outlet Thread Type BSPP
Wetted Material Stainless Steel, Tungsten Carbide, PTFE, Chemically Resistant Fluoroelastomer
Type Back Pressure Regulator
Minimum Regulated Pressure (MPa) 0.1
