High Pressure Pneumatic Fluid Regulator, 5000 psi (360 bar) max fluid inlet pressure, 600-3600 psi (40-320 bar) regulated pressure range

High Pressure Pneumatic Fluid Regulator, 5000 psi (360 bar) max fluid inlet pressure, 600-3600 psi (40-320 bar) regulated pressure range

Regular price
$3,030.00
Sale price
$3,030.00
Quantity must be 1 or more


For use in air-assisted spray systems to ensure accurate, positive control of fluid pressure to a spray gun, dispensing valve, or atomizing head.

UPC Product: 00633955801783
Family Code: FAMCNV
Unit of Measure: EA
Height: 8.6 IN   |  21.844 CM
Length: 17.5 IN   |  44.45 CM
Width: 10.5 IN   |  26.67 CM
Volume: .914 FT3   |  .026 M3
Chargeable Weight: 14.08 LBS  | 6.39 KG

Technical Specifications

Actuation Type Air
Gauge Port Size (cm) 0.635
Gauge Port Size (in) 1/4
Gauge Port Size (mm) 6.35
Gauge Port Type BSPP
Includes Gauge, Medidor
Inlet Size (cm) 1.905
Inlet Size (in) 3/4
Inlet Size (mm) 19.05
Inlet Thread Type BSPP
Maximum Flow Rate (GPM) 12.3
Maximum Flow Rate (L/min) 46.6
Maximum Operating Temperature (°C) 80
Maximum Operating Temperature (°F) 176
Maximum Regulated Pressure (bar) 317
Maximum Regulated Pressure (kPa) 31700
Maximum Regulated Pressure (psi) 4600
Maximum Working Pressure (bar) 344
Maximum Working Pressure (kPa) 34400
Maximum Working Pressure (psi) 5000
Minimum Operating Temperature (°C) 10
Minimum Operating Temperature (°F) 50
Minimum Regulated Pressure (bar) 40
Minimum Regulated Pressure (kPa) 4000
Minimum Regulated Pressure (psi) 600
Outlet Size (cm) 1.905
Outlet Size (in) 3/4
Outlet Size (mm) 19.05
Outlet Thread Type BSPP
Wetted Material Stainless Steel, Carbide
Gauge Port Thread Gender Female
Type Fluid Regulator
Maximum Fluid Pressure (bar) 345
Maximum Fluid Pressure (kPa) 34450
Maximum Fluid Pressure (psi) 5000
Maximum Fluid Pressure (MPa) 34.5
Inlet Thread Gender Female
Outlet Thread Gender Female
Maximum Regulated Pressure (MPa) 31.7
Maximum Working Pressure (MPa) 34.4
Minimum Regulated Pressure (MPa) 4
