Regulate air powered equipment connected to the Fluid Defender and Pulse Fluid Defender to help prevent pump cavitation or tank overflow.
Feel free to call or chat with us for recommendations.
📦
Ships in 2-3 weeks, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
- Control air operated pumps and air actuated control valves
- Continuously powered during normal operation with the air control solenoid valve being open to provide air pressure to the controlled equipment
- When the Fluid Defender detects an alarm condition in the same channel as the air control solenoid valve, the solenoid is deactivated causing the connected equipment to deactivate
UPC Product: 00769946712476
Family Code: FAMLVL
Unit of Measure: EA
Height:
2 IN
| 5.08 CM
Length:
10.75 IN
| 27.305 CM
Width:
9.1 IN
| 23.114 CM
Volume:
.113 FT3
| .003 M3
Chargeable Weight:
1.179 LBS
| 0.535 KG
Technical Specifications
| For Use With | Fluid Defender |
|---|---|
| Type | Air Regulator |
| Maximum Operating Pressure (psi) | 145 |
| Maximum Operating Temperature (°F) | 122 |
| Maximum Storage Temperature (°F) | 185 |
| Minimum Operating Pressure (psi) | 36 |
| Minimum Operating Temperature (°F) | 14 |
| Air Inlet Size (in) | 3/8 |
| Air Inlet Thread Type | NPT |
| Maximum Air Flow Rate (CFM) | 93 |
