UPC Product: 00633955557680
Family Code: FAMINK
Unit of Measure: EA
Height:
21.6 IN
| 54.864 CM
Length:
66 IN
| 167.64 CM
Width:
19.2 IN
| 48.768 CM
Volume:
15.84 FT3
| .449 M3
Chargeable Weight:
254 LBS
| 115.21 KG
Technical Specifications
| Type | Piston Transfer Pump |
|---|---|
| Air Inlet Size (in) | 3/4 |
| Air Inlet Size (mm) | 19.05 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Application | Industrial |
| Compatible Material | Ink |
| Fluid Outlet Size (in) | 1-1/2 |
| Fluid Outlet Size (mm) | 38.1 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Type | Sealed Wet Cup |
| Includes | DataTrak Monitor |
| Maximum Air Inlet Pressure (bar) | 6.9 |
| Maximum Air Inlet Pressure (kPa) | 690 |
| Maximum Air Inlet Pressure (psi) | 100 |
| Maximum Continuous Cycle Rate (CPM) | 60 |
| Maximum Flow Rate (GPM) | 8 |
| Maximum Flow Rate (L/min) | 30.3 |
| Maximum Operating Temperature (°C) | 82 |
| Maximum Operating Temperature (°F) | 180 |
| Maximum Working Pressure (bar) | 179 |
| Maximum Working Pressure (kPa) | 17900 |
| Maximum Working Pressure (psi) | 2600 |
| Model | Check-Mate |
| Portable | Non-Portable |
| Power Type | Pneumatic |
| Pump Ratio | 26:1 |
| Standards Met | CE |
| Maximum Working Pressure (MPa) | 17.9 |
| Package Options | DataTrak |
