UPC Product: 00633955557710
Family Code: FAMINK
Unit of Measure: EA
Height:
19.2 IN
| 48.768 CM
Length:
69.6 IN
| 176.784 CM
Width:
16.8 IN
| 42.672 CM
Volume:
12.99 FT3
| .368 M3
Chargeable Weight:
234 LBS
| 106.14 KG
Technical Specifications
| Type | Pneumatic Piston Pump |
|---|---|
| Air Inlet Size (cm) | 1.905 |
| Air Inlet Size (in) | 3/4 |
| Air Inlet Size (mm) | 19.05 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Application | Industrial |
| Compatible Material | Ink |
| Fluid Outlet Size (cm) | 3.81 |
| Fluid Outlet Size (in) | 1-1/2 |
| Fluid Outlet Size (mm) | 38.1 |
| Fluid Outlet Thread Gender | Male |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Type | Sealed Wet Cup |
| Maximum Air Inlet Pressure (bar) | 103.4 |
| Maximum Air Inlet Pressure (kPa) | 10340 |
| Maximum Air Inlet Pressure (psi) | 1500 |
| Maximum Continuous Cycle Rate (CPM) | 60 |
| Maximum Operating Temperature (°C) | 82 |
| Maximum Operating Temperature (°F) | 180 |
| Maximum Working Pressure (bar) | 159 |
| Maximum Working Pressure (kPa) | 15900 |
| Maximum Working Pressure (psi) | 2300 |
| Model | Check-Mate |
| Portable | Non-Portable |
| Pump Ratio | 1.6:1 |
| Maximum Working Pressure (MPa) | 15.9 |
